Description

Application:

For wooden doors between 32-50mm thick
19mm diameter handle
Sprung
Supplied with bolt-through fixings
Concealed fixings
Non-handed

Specification:

Available in SS316 and SS304 stainless steel
Handle Length: 135mm
Handle Projection: 60mm
Rose Diameter: 54mm
Rose Projection: 8mm
Please refer to separate page for
accessories
Supplied with push-on rose as standard
Available with screw-on rose upon request

Finish: SS – Satin Stainless Steel
PB – PVD
PS – Polished Stainless Steel

Standards:
Tested to BS EN 1906 : 2012
4 7 – B 0 5 0 B
BS EN 1634 Part 1 : 2000 assessed for use
on 60 minute timber fire doors, and 240
minute steel doors
Corrosion testing – 480 hours – EN 1670
Grade 4
